DIN Rail Pluggable Terminal Block - 10 Pole

This 10-pole rail mount terminal block is designed for easy horizontal or vertical mounting on DIN rails.

It includes polarised mouldings for correct and safe connections and the reversible feature on DIN clips simplifies mounting.

Made from durable UL94-V0 flame retardant PA66, this terminal block is built for longevity and safety. We also have a 6 Pole and an 8 Pole version available.

Features

• Horizontal & vertical orientations
• Polarised moldings
• Can be reversed on DIN clips
• 5.08mm/0.2" pitch
• Moulded in green UL94-V0 flame retardant PA 66
• 2.5mm2 (28-14AWG)
• UL Approved
• 10 poles
• Model number: Camdenboss CTBPD96HJ/10

Specifications

External Length (mm)	52.2
External Width (mm)	42
External Height (mm)	31.5
Weight (G)	22.3
Base Material	Plastic
Material Type	Polyamide
Colour	Green
UL Rating	UL94-V0
General Current Rating (A)	15
UL Current Rating (A)	15
UL Voltage Rating (V)	300
Orientation	Horizontal
Pitch (mm)	5.08
CE Approval	Yes
UL Approval	Yes
Cable Size (AWG)	28 to 14
Cable Entry Solid Wire (mm2)	1.5
Cable Entry Stranded Wire (mm2)	1.5
No. of Poles	10
DIN Rail Mounting	Yes

Resources

• Datasheet

Package Contents

• 1x DIN Rail Pluggable Terminal Block - 10 Pole
